Amazon Redshift vs Aurora: 9 Critical Differences

on Data Warehouse, Amazon Redshift, Database, Tutorial • August 12th, 2019 • Write for Hevo

AuroraDB is a relational database engine that comes as one of the options in the AWS Relational Database as a service. Amazon Redshift, on the other hand, is another completely managed database service from Amazon that can scale up to petabytes of data. Even though the ultimate aim of both these services is to let customers store and query data without getting involved in the infrastructure aspect, these two services are different in a number of ways.

In this post, we will explore Amazon Redshift Vs Aurora – how these two databases compare with each other in the case of various elements and which one would be the ideal choice in different kinds of use cases. In the end, you will be in the position to choose the best platform based on your business requirements. Let’s get started.

Table of Contents

Introduction to Amazon Redshift

Amazon Redshift Logo
Image Source

Redshift is a completely managed database service that follows a columnar data storage structure. Redshift offers ultra-fast querying performance over millions of rows and is tailor-made for complex queries over petabytes of data. Redshift’s querying language is similar to Postgres with a smaller set of datatype collection.

With Redshift, customers can choose from multiple types of instances that are optimized for performance and storage. Redshift can scale automatically in a matter of minutes in the case of the newer generation nodes. Automatic scaling is achieved by adding more nodes. A cluster can only be created using the same kind of nodes. All the administrative duties are automated with little intervention from the customer needed. You can read more on Redshift Architecture here.

Redshift uses a multi-node architecture with one of the nodes being designated as a leader node. The leader node handles client communication, assigning work to other nodes, query planning, and query optimization. Redshift’s pricing combines storage and computing with the customers and does not have the pure serverless capability. Redshift offers a unique feature called Redshift spectrum which basically allows the customers to use the computing power of the Redshift cluster on data stored in S3 by creating external tables.

To know more about Amazon Redshift, visit this link.

Introduction to Amazon Aurora

Amazon Aurora Logo
Image Source

AuroraDB is a MySQL and Postgres compatible database engine; which means if you are an organization that uses either of these database engines, you can port your database to Aurora without changing a line of code. Aurora is enterprise-grade when it comes to performance and availability. All the traditional database administration tasks like hardware provisioning, backing up data, installing updates, and the likes are completely automated.

Aurora can scale up to a maximum of 64 TB. It offers replication across multiple availability zones through what Amazon calls multiAZ deployment. Customers can choose from multiple types of hardware specifications for their instances depending on the use cases. Aurora also offers a serverless feature that enables a completely on-demand experience where the database will scale down automatically in case of lower loads and vice-versa. In this mode, customers only need to pay for the time the database is active, but it comes at the cost of a slight delay in response to requests that comes during the time database is completely scaled down.

Amazon offers a replication feature through its multiAZ deployment strategy. This means your data is going to be replicated across multiple regions automatically and in case of a problem with your master instance, Amazon will switch to one among the replicas without affecting any loads.

Aurora architecture works on the basis of a cluster volume that manages the data for all the database instances in that particular cluster. A cluster volume spans across multiple availability zones and is effectively virtual database storage. The underlying storage volume is on top of multiple cluster nodes which are distributed across different availability zones. Separate from this, the Aurora database can also have read-replicas. Only one instance usually serves as the primary instance and it supports reads as well as writes. The rest of the instances serve as read-replicas and load balancing needs to be handled by the user. This is different from the multiAZ deployment, where instances are located across the availability zone and support automatic failover.

To know more about Amazon Aurora, visit this link.

Introduction to OLAP and OLTP

OLAP vs OLTP
Image Source

The term OLAP stands for Online Analytical Processing. OLAP analyses business data on a multidimensional level and allows for complicated computations, trend analysis, and advanced data modeling. Business Performance Management, Planning, Budgeting, Forecasting, Financial Reporting, Analysis, Simulation Models, Knowledge Discovery, and Data Warehouse Reporting are all built on top of it. End-users may utilize OLAP to do ad hoc analysis of data in many dimensions, giving them the knowledge and information they need to make better decisions.

Online Transaction Processing, or OLTP, is a form of data processing that involves completing several transactions concurrently, for example, online banking, shopping, order entry, or sending text messages. Traditionally, these transactions have been referred to as economic or financial transactions, and they are documented and secured so that an organization may access the information at any time for accounting or reporting reasons.

To know more about OLAP and OLTP, visit this link.

Simplify Data Analysis using Hevo’s No-code Data Pipeline

Hevo Data helps you directly transfer data from 100+ data sources (including 30+ free sources) to Business Intelligence tools, Data Warehouses, or a destination of your choice in a completely hassle-free & automated manner. Hevo is fully managed and completely automates the process of not only loading data from your desired source but also enriching the data and transforming it into an analysis-ready form without having to write a single line of code. It helps transfer data from a source of your choice to a destination of your choice for free. Its fault-tolerant architecture ensures that the data is handled in a secure, consistent manner with zero data loss.

Hevo takes care of all your data preprocessing needs required to set up the integration and lets you focus on key business activities and draw a much powerful insight on how to generate more leads, retain customers, and take your business to new heights of profitability. It provides a consistent & reliable solution to manage data in real-time and always have analysis-ready data in your desired destination.

Get Started with Hevo for Free

Check out what makes Hevo amazing:

  • Real-Time Data Transfer: Hevo with its strong Integration with 100+ Sources (including 30+ Free Sources), allows you to transfer data quickly & efficiently. This ensures efficient utilization of bandwidth on both ends.
  • Data Transformation: It provides a simple interface to perfect, modify, and enrich the data you want to transfer.
  • Secure: Hevo has a fault-tolerant architecture that ensures that the data is handled in a secure, consistent manner with zero data loss.
  • Tremendous Connector Availability: Hevo houses a large variety of connectors and lets you bring in data from numerous Marketing & SaaS applications, databases, etc. such as HubSpot, Marketo, MongoDB, Oracle, Salesforce, Redshift, etc. in an integrated and analysis-ready form.
  • Simplicity: Using Hevo is easy and intuitive, ensuring that your data is exported in just a few clicks.
  • Completely Managed Platform: Hevo is fully managed. You need not invest time and effort to maintain or monitor the infrastructure involved in executing codes.
  • Live Support: The Hevo team is available round the clock to extend exceptional support to its customers through chat, email, and support calls.
Sign up here for a 14-Day Free Trial!

Factors that Drive Redshift Vs Aurora Decision

Both Redshift and Aurora are popular database services in the market. There is no one-size-fits-all answer here, instead, you must choose based on your company’s needs, budget, and other factors to make a Redshift vs Aurora decision. The primary factors that influence the Redshift vs Aurora comparison are as follows:

Redshift vs Aurora: Scaling

Redshift offer scaling by adding more nodes or upgrading the nodes. Redshift scaling can be done automatically, but the downtime in the case of Redshift is more than that of Aurora. Redshift’s concurrency scaling feature deserves a mention here. This feature is priced separately and allows a virtually unlimited number of concurrent users with the same performance if the budget is not a problem.

Aurora enables scaling vertically or horizontally. Vertical scaling is through upgrading instance types and in the case of multiAZ deployment, there is minimal downtime associated with this. Otherwise, the scaling can be scheduled during the maintenance time window of the database. Aurora horizontal scaling is through read-replicas and an aurora database can have at most 15 read-replicas at the same time. Aurora compute scaling is different from storage scaling and what we mentioned above is only about compute scaling. Aurora storage scaling is done by changing the maximum allocated storage space or storage hardware type like SSD or HDD.

Redshift vs Aurora: Storage Capacity

Redshift can practically scale to petabytes of data and run complex queries out of them. Redshift can support up to 60 user-defined databases per cluster. Aurora, on the other hand, has a hard limit of 64 TB and the number of database instances is limited at 40.

Redshift vs Aurora: Data Loading

Redshift ETL also supports the COPY command for inserting data. It is recommended to insert data split into similar-sized chunks for better performance. In the case of data already existing in Redshift, you may need to use temporary tables since Redshift does not ensure unique key constraints. A detailed account of how to do ETL on Redshift can be found here.

Data loading in Aurora will depend on the type of instance type that is being used. In the case of MySQL compatible instances, you would need to use the mysqlimport command or LOAD DATA IN FILE command depending on whether the data is from a MySQL table or file. Aurora with Postgres can load data with the COPY command.

An alternative to this custom script-based ETL is to use a hassle-free Data Pipeline Platform like Hevo which can offer a very smooth experience implementing ETL on Redshift or Aurora with support for real-time data sync, in-flight data transformations, and much more.

Redshift vs Aurora: Data Structure

Aurora follows row-oriented storage and supports the complete data types in both MySQL and Postgres instance types. Aurora is also an ACID complaint. Redshift uses a columnar storage structure and is optimized for column level processing than complete row level processing.

Redshift’s Postgres-like querying layer misses out on many data types which are supported by Aurora’s Postgres instance type. Redshift does not support consistency among the ACID properties and only exhibits eventual consistency. It does not ensure referential integrity and unique key constraints.

Redshift vs Aurora: Performance

Redshift offers fast read performance and over a larger amount of data when compared to Aurora. Redshift excels specifically in the case of complicated queries spanning millions of rows.

Aurora offers better performance than a traditional MySQL or Postgres instance. Aurora’s architecture disables the InnoDB change buffer for distributed storage leading to poor performance in the case of write-heavy operations. If your use case updates are heavy, it may be sensible to use traditional databases like MySQL or Postgres than Aurora.

Both the services offer performance optimizations using sharding and key distribution mechanisms. Redshift’s SORT KEY and DIST KEY need to be configured here for improvements in complex queries involving JOINs.

Aurora is optimized for OLTP workloads and Redshift is preferred in the case of OLAP workloads. Transactional workloads are not recommended in Redshift since it supports only eventual consistency.

Redshift vs Aurora: Security

When it comes to Security, there is nothing much to differentiate between the two services. With both being part of the AWS portfolio, they offer the complete set of security requirements and compliance.  Data is ensured to be encrypted at rest and motion. There are provisions to establish virtual private clouds and restrict usage based on Amazon’s Identity and Access management. Other than these, customers can also use the specific security features that are part of Postgres and MySQL instance types with Aurora.

Redshift vs Aurora: Maintenance

Both Aurora and Redshift are completely managed services and required very little maintenance. Redshift because of its delete marker-based architecture needs the VACUUM command to be executed periodically to reclaim the space after entries are deleted.  These can be scheduled periodically, but it is a recommended practice to execute this command in case of heavy updates and delete workload. Redshift also needs the ANALYZE command to be executed periodically to keep the metadata up to data for query planning.

Redshift vs Aurora: Pricing

Redshift pricing is including storage and compute power. Redshift starts at .25$ per hour for the dense compute instance types per node. Dense compute is the recommended instance type for up to 500 GB of data. For the higher-spec dense storage instance types, pricing starts at .85$. It is to be noted that these two services are designed for different use cases and pricing can not be compared independent of the customer use cases.

Aurora MySQL starts with .041$ per hour for its lowest spec instance type. Aurora Postgres starts at .082$ per hour for the same type of instance. The memory-optimized instance types with higher performance start for .29$ for both MySQL and Postgres instance types. Aurora’s serverless instances are charged based on ACU hours and start at .06$ per ACU hour. Storage and IO are charged separately for Aurora. It costs .1 $ per GB per month and .2$ per 1 million requests. Aurora storage pricing is based on the maximum storage ever used by the cluster and it is not possible to reclaim space after being deleted without re instantiating the database.

An obvious question after such a long comparison is about how to decide when to use Redshift and Aurora for your requirement. The following section summarizes the scenarios in which using one of them may be beneficial over the other.

Redshift vs Aurora: Use Cases

Use Cases of Amazon Redshift

  1. The requirement is an Online analytical processing workload and not transactional.
  2. You have a high analytical workload and running on your transactional database will hurt the performance.
  3. Your data volume is in hundreds of TBs and you anticipate more data coming in.
  4. You are willing to let go of the consistency compliance and will ensure the uniqueness of your keys on your own.
  5. You are ready to put your head into designing SORT KEYS and DIST KEYS to extract the maximum performance.

Use Cases of Amazon Aurora

  1. You want to relieve yourself of the administrative tasks of managing a database but want to stick with  MySQL or Postgres compatible querying layer.
  2. You want to stay with traditional databases like MySQL or Postgres but want better read performance at the cost of slightly lower write and update performance.
  3. Your storage requirements are only in the TBs and do not anticipate 100s of TBs of data in the near future.
  4. You have an online transactional processing use case and want quick results with a smaller amount of data.
  5. Your OLTP workloads are not interrupted by analytical workloads
  6. Your analytical workloads do not need to process millions of rows of data.

Conclusion

This article gave a comprehensive guide to Redshift vs Aurora. You got a deeper understanding of Redshift and Aurora. Now, you are in the position to choose the best among the two based on your business goals and requirements. To conclude, the Redshift vs Aurora decision is entirely based on the company’s goals, resources, and also a matter of personal preference.
