Spring Batch Jobs: How to Setup Batch Processing in Spring Simplified 101

on Batch Processing, Spring, Spring Boot, Tutorials • April 29th, 2022 • Write for Hevo

Spring Batch Jobs_FI

Because of the increase in data collection, organisations rely on bulk processing to effectively handle large amounts of data. It includes automated operations as well as the complex processing of large datasets without the need for user interaction. As a result, organisations use batch processing frameworks such as Spring Batch to simplify the overall workflow and handle billions of events every day.

Spring Batch Processing can aid in the development of robust batch processing applications and even the management of event-driven operations via Spring Batch Jobs.

In this article, you will gain information about Spring Batch Jobs. You will also gain a holistic understanding of Batch Processing, its key features, Spring framework, Spring Batch, and a step-by-step guide to developing a Spring Boot application through Spring Batch Jobs. Read along to find out in-depth information about Spring Batch Jobs.

Table of Contents

Prerequisites

  • Installation of JDK (Java Development Kit)
  • Basic Knowledge in Spring Boot

What is Batch Processing?

Herman Hollerith, an American inventor who invented the first tabulating machine, used the Batch Processing method for the first time in the 19th century. This device, which was capable of counting and sorting data organized on punched cards, became the forerunner of the modern computer. The cards, as well as the information on them, could then be collected and processed in batches. Large amounts of data could be processed more quickly and accurately with this innovation than with manual entry methods.

Batch processing is an efficient way of running a large number of iterative data jobs. With the right amount of computing resources present, the batch method allows you to process data with little to no user interaction.

After you’ve collected and saved your data, you can use the batch processing method to process it during an event known as a “batch window.” It offers an efficient workflow layout by prioritizing processing tasks and completing data jobs when it makes the most sense.

Batch Processing is a method for processing large amounts of data in a consistent manner. When computing resources are available, the batch method allows users to process data with little or no user interaction.

The Batch Reference Architecture is depicted in a simplified form in the diagram below. A Batch Operation is usually encapsulated by a Job, which is made up of several Steps. Each Step typically employs a single ItemReader, ItemProcessor, and ItemWriter. A JobLauncher executes a job, and metadata about the jobs that have been configured and executed is saved in a JobRepository. It defines the fundamental concepts and terms used by Spring Batch Parallel Processing.

Spring Batch Jobs: Architecture| Hevo Data
Image Source

Key Features of Batch Processing

Batch Processing has become popular due to its numerous benefits for enterprise data management. It has several advantages for businesses:

  • Efficiency: Batch Processing allows a company to process jobs when computing or other resources are readily available. Companies can schedule batch processes for non-urgent tasks and prioritize time-sensitive tasks. Batch systems can also run in the background in order to reduce processor stress.
  • Simplicity: When compared to Stream Processing, Batch Processing is a less complex system that does not require any special hardware or system support. It requires less maintenance for data input.
  • Faster Business Intelligence: Batch Processing enables businesses to quickly process large volumes of data which results in faster and efficient Business Intelligence. In Batch processing, many records can be processed at once which reduces the processing time and ensures that data is delivered on time. Additionally, since numerous jobs can be handled simultaneously, Business intelligence is available faster than earlier.
  • Improved Data Quality: By automating most or all components of a processing job and minimizing user interaction, batch processing reduces the likelihood of errors. Precision and accuracy are improved to achieve a higher level of data quality.

Process Data Seamlessly Using Hevo’s No-Code Data Pipeline

Hevo Data, a Fully-managed Data Pipeline platform, can help you automate, simplify & enrich your data replication process in a few clicks. With Hevo’s wide variety of connectors and blazing-fast Data Pipelines, you can extract & load data from 100+ Data Sources (including 40+ Free Sources) straight into your Data Warehouse or any Databases. To further streamline and prepare your data for analysis, you can process and enrich raw granular data using Hevo’s robust & built-in Transformation Layer without writing a single line of code!

GET STARTED WITH HEVO FOR FREE[/hevoButton]

Hevo is the fastest, easiest, and most reliable data replication platform that will save your engineering bandwidth and time multifold. Try our 14-day full access free trial to experience an entirely automated hassle-free Data Replication!

What is Spring Framework?

Spring Batch Jobs: Spring Framework| Hevo Data
Image Source

The Spring Framework is a free and open-source application framework that provides infrastructure support for Java developers. Spring is one of the most popular Java Enterprise Edition (Java EE) frameworks that assist developers in creating high-performance applications using simple Java objects (POJOs). It offers a comprehensive programming and configuration model for modern Java-based enterprise applications running on any platform.

Spring’s infrastructure support at the application level is a key component: Spring focuses on the “plumbing” of enterprise applications so that teams can focus on the business logic based on business logic without being tethered to specific deployment environments.

What is Spring Batch?

Spring Batch Jobs: Spring Batch Architecture| Hevo Data
Image Source

Spring Batch is a lightweight, all-in-one batch framework that facilitates the development of dependable batch applications that are critical to enterprise systems’ day-to-day operations. Spring Batch includes reusable features including Logging/Tracing, Transaction Management, Task Processing Statistics, Job Restart, and Resource Management, which are required when processing large amounts of data. It also encompasses more advanced technical features and solutions that will enable exceptionally high-performance batch jobs through optimization and partitioning approaches.

Spring Batch is the de facto standard for batch processing on the Java Virtual Machine (JVM). Its implementation of common batch patterns, such as chunk-based processing and partitioning, lets you create high-performing, scalable batch applications that are resilient enough for your most mission-critical processes. Spring Boot provides an additional level of production-grade features to let you speed up the development of your batch processes.

Spring Batch Jobs: Developing a Spring Boot Application

In this example, a Spring Boot application is developed that reads data from a CSV file and stores it in an SQL Database.

The steps involved in developing a Spring Boot application in the process of setting up Spring Batch jobs are as follows:

1) Spring Batch Jobs: Application Setup

The steps are as follows:

  • Step 1: On your browser, navigate to the Spring Intializr.
  • Step 2: Set the name of your project as per your choice. You can name it “springbatch“.
  • Step 3: You can add spring web, h2 database, lombok, spring batch, and spring data jpa as the project dependencies.
  • Step 4: A project zip file will be generated. Now, click on the “generate” button to download the file.
  • Step 5: After downloading, you can decompress the downloaded file and open it in your IDE.

2) Spring Batch Jobs: Data Layer

The steps are as follows:

  • Step 1: In the root project package, create a new package named domain.
  • Step 2: Create a file named as Customer in the domain package you created. Then add the following code into it.
@Entity(name = "person")
@Getter // Lombok annotation to generate Getters for the fields
@Setter // Lombok annotation to generate Setters for the fields
@AllArgsConstructor // Lombok annotation to generate a constructor will all of the fields in the class
@NoArgsConstructor // Lombok annotation to generate an empty constructor for the class
@EntityListeners(AuditingEntityListener.class)
public class Customer {
    @Id // Sets the id field as the primary key in the database table
    @Column(name = "id") // sets the column name for the id property
    @GeneratedValue(strategy = GenerationType.AUTO) // States that the id field should be autogenerated
    private Long id;

    @Column(name = "last_name")
    private String lastName;
    @Column(name = "first_name")
    private String firstName;

    // A method that returns firstName and Lastname when an object of the class is logged
    @Override
    public String toString() {
        return "firstName: " + firstName + ", lastName: " + lastName;
    }
}

The class above includes an id field for the database’s primary key, as well as lastName and firstName fields retrieved from the csv file used in this example (data.csv file).

3) Spring Batch Jobs: Repository Layer

The steps are as follows:

  • Step 1: In the root project package, create a new package named repositories.
  • Step 2: Create an interface named CustomerRepository in the previously created repositories package and add the following code.
// The interface extends JpaRepository that has the CRUD operation methods
public interface CustomerRepository extends JpaRepository<Customer, Long> {
}

4) Spring Batch Jobs: Processor

The steps are as follows:

  • Step 1: In the root project package, create a new package named processor.
  • Step 2: Create a new Java file named CustomerProcessor in the processor package. Then, add the following code into it.
public class CustomerProcessor implements ItemProcessor<Customer, Customer> {
    // Creates a logger
    private static final Logger logger = LoggerFactory.getLogger(CustomerProcessor.class);
    // This method transforms data form one form to another.
    @Override
    public Customer process(final Customer customer) throws Exception {
        final String firstName = customer.getFirstName().toUpperCase();
        final String lastName = customer.getLastName().toUpperCase();
        // Creates a new instance of Person
        final Customer transformedCustomer = new Customer(1L, firstName, lastName);
        // logs the person entity to the application logs
        logger.info("Converting (" + customer + ") into (" + transformedCustomer + ")");
        return transformedCustomer;
    }
}

The class here converts data from one form to another. The ItemProcessor <I, O> accepts input data (I), transforms it, and returns the result as output data (O).

The Customer entity is declared as both the input and output in this case. As a result, the data form is preserved.

5) Spring Batch Jobs: Configuration Layer

The steps are as follows:

  • Step 1: In the root project package, create a new package named config. All of our configurations will be included in this package.
  • Step 2: Create a new Java file named BatchConfiguration in the config package. Then add the following code into it.
@Configuration // Informs Spring that this class contains configurations
@EnableBatchProcessing // Enables batch processing for the application
public class BatchConfiguration {

    @Autowired
    public JobBuilderFactory jobBuilderFactory;

    @Autowired
    public StepBuilderFactory stepBuilderFactory;

    @Autowired
    @Lazy
    public CustomerRepository customerRepository;

    // Reads the sample-data.csv file and creates instances of the Person entity for each person from the .csv file.
    @Bean
    public FlatFileItemReader<Customer> reader() {
        return new FlatFileItemReaderBuilder<Customer>()
        .name("customerReader")
        .resource(new ClassPathResource("data.csv"))
        .delimited()
        .names(new String[]{"firstName", "lastName"})
        .fieldSetMapper(new BeanWrapperFieldSetMapper<>() {{
        setTargetType(Customer.class);
        }})
        .build();
    }

    // Creates the Writer, configuring the repository and the method that will be used to save the data into the database
    @Bean
    public RepositoryItemWriter<Customer> writer() {
        RepositoryItemWriter<Customer> iwriter = new RepositoryItemWriter<>();
        iwriter.setRepository(customerRepository);
        iwriter.setMethodName("save");
        return iwriter;
    }

    // Creates an instance of PersonProcessor that converts one data form to another. In our case the data form is maintained.
    @Bean
    public CustomerProcessor processor() {
        return new CustomerProcessor();
    }

    // Batch jobs are built from steps. A step contains the reader, processor and the writer.
    @Bean
    public Step step1(ItemReader<Customer> itemReader, ItemWriter<Customer> itemWriter)
    throws Exception {

        return this.stepBuilderFactory.get("step1")
        .<Customer, Customer>chunk(5)
        .reader(itemReader)
        .processor(processor())
        .writer(itemWriter)
        .build();
    }

    // Executes the job, saving the data from .csv file into the database.
    @Bean
    public Job customerUpdateJob(JobCompletionNotificationListener listener, Step step1)
    throws Exception {

        return this.jobBuilderFactory.get("customerUpdateJob").incrementer(new RunIdIncrementer())
        .listener(listener).start(step1).build();
    }
}
  • Step 3: Create a new Java class named JobCompletionNotificationListener in the config package and add the following code.
@Component
public class JobCompletionListener extends JobExecutionListenerSupport {
    // Creates an instance of the logger
    private static final Logger log = LoggerFactory.getLogger(JobCompletionListener.class);
    private final CustomerRepository customerRepository;

    @Autowired
    public JobCompletionListener(CustomerRepository customerRepository) {
        this.customerRepository = customerRepository;
    }

    // The callback method from the Spring Batch JobExecutionListenerSupport class that is executed when the batch process is completed
    @Override
    public void afterJob(JobExecution jobExecution) {
        // When the batch process is completed the the users in the database are retrieved and logged on the application logs
        if (jobExecution.getStatus() == BatchStatus.COMPLETED) {
        log.info("!!! JOB COMPLETED! verify the results");
        customerRepository.findAll()
        .forEach(person -> log.info("Found (" + person + ">) in the database.") );
        }
    }
}

What Makes Hevo’s Data Processing Best-In-Class

Processing data can be a mammoth task without the right set of tools. Hevo’s automated platform empowers you with everything you need to have a smooth Data Collection, Processing, and Replication experience. Our platform has the following in store for you!

  • Exceptional Security: A Fault-tolerant Architecture that ensures consistency and robust security with  Zero Data Loss.
  • Built to Scale: Exceptional Horizontal Scalability with Minimal Latency for Modern-data Needs.
  • Built-in Connectors: Support for 100+ Data Sources, including Databases, SaaS Platforms, Files & More. Native Webhooks & REST API Connector available for Custom Sources.
  • Data Transformations: Best-in-class & Native Support for Complex Data Transformation at fingertips. Code & No-code Fexibilty designed for everyone.
  • Smooth Schema Mapping: Fully-managed Automated Schema Management for incoming data with the desired destination.
  • Blazing-fast Setup: Straightforward interface for new customers to work on, with minimal setup time.
  • Live Support: The Hevo team is available round the clock to extend exceptional support to its customers through chat, email, and support calls.
SIGN UP HERE FOR A 14-DAY FREE TRIAL

6) Spring Batch Jobs: Controller Layer

The steps are as follows:

  • Step 1: In the root project package, create a new package named controllers.
  • Step 2: Create a Java class named BatchController in the previously created controllers package and add the following code.
@RestController
@RequestMapping(path = "/batch")// Root path
    public class BatchController {
    @Autowired
    private JobLauncher jobLauncher;
    @Autowired
    private Job job;

    // The function below accepts a GET request to invoke the Batch Process and returns a String as response with the message "Batch Process started!!".
    @GetMapping(path = "/start") // Start batch process path
    public ResponseEntity<String> startBatch() {
        JobParameters Parameters = new JobParametersBuilder()
        .addLong("startAt", System.currentTimeMillis()).toJobParameters();
        try {
        jobLauncher.run(job, Parameters);
        } catch (JobExecutionAlreadyRunningException | JobRestartException
        | JobInstanceAlreadyCompleteException | JobParametersInvalidException e) {

        e.printStackTrace();
        }
        return new ResponseEntity<>("Batch Process started!!", HttpStatus.OK);
    }
}

7) Spring Batch Jobs: Application Configuration

The steps are as follows:

  • Step 1: Add the following code to the application.properties file in the resource directory.
# Sets the server port from where we can access our application
server.port=8080
# Disables our batch process from automatically running on application startup
spring.batch.job.enabled=false

8) Spring Batch Jobs: Testing

The steps are as follows:

  • Step 1: To begin the batch process, open Postman and send a GET request to http://localhost:8080/batch/start.
  • Step 2: From the application logs you can know that the batch process starts running after you send the GET request.

Conclusion

In this article, you have learned about Spring Batch Jobs. This article also provided information on Batch Processing, its key features, Spring framework, Spring Batch, and a step-by-step guide to developing a Spring Boot application through Spring Batch Jobs.
