How to Sync Data from PostgreSQL to Google BigQuery in 2 Easy Methods

Are you trying to derive deeper insights from PostgreSQL by moving the data into a Data Warehouse like Google BigQuery? Well, you have landed on the right article. Now, it has become easier to replicate data from PostgreSQL to BigQuery.

This article will give you a brief overview of PostgreSQL and Google BigQuery. You will also get to know how you can set up your PostgreSQL to BigQuery integration using 2 methods. Moreover, the limitations in the case of the manual method will also be discussed in further sections. Read along to decide which method of connecting PostgreSQL to BigQuery is best for you.

Introduction to PostgreSQL

PostgreSQL, although primarily used as an OLTP Database, is one of the popular tools for analyzing data at scale. Its novel architecture, reliability at scale, robust feature set, and extensibility give it an advantage over other databases.

Features of PostgreSQL

• PostgeSQL can support a wide range of data types including floating-point numbers, JSON etc.
• It offers  support for stored procedures and functions in a variety of languages, such as SQL, PL/pgSQL, Python, and C. This helps you to create custom logic at the database level that will be useful for building applications.
• As PostgreSQL has the capability for managing huge data volumes, you can build applications that need quick data processing and retrieval. Instances of such applications include:

CMS: Postgresql’s ability to manage huge structured data and unstructured data and its features for full-text and advanced search features help it simple to arrange and retrieve content for your purposes.

eCommerce: As Postgres can manage huge transactional data volume, it can run eCommerce platforms. You can manage a high volume of read and write operations by using Postgres.  Also, you can streamline managing product related information and metadata using the built-in support for advanced data types such as JSON and hstore.

As mentioned above, as the data volume and velocity need to increase, it requires a huge effort and expertise to optimize PostgreSQL compared to a data warehouse to make it run analytics queries within the desired time.

Due to this, there can be an impact on your transaction workloads directly or indirectly. This is why most organizations prefer a separate system for analytical workloads.

If that solution is in the cloud additional benefits like elasticity in scaling, minimal upfront cost, etc. come to play. Hence, companies choose to move data from PostgreSQL to BigQuery.

Introduction to Google BigQuery

Google BigQuery is a serverless, cost-effective, and highly scalable Data Warehousing platform with Machine Learning capabilities built-in.

The Business Intelligence Engine is used to carry out its operations. It integrates speedy SQL queries with Google’s infrastructure’s processing capacity to manage business transactions, data from several databases, and access control restrictions for users seeing and querying data.

BigQuery is used by several firms, including UPS, Twitter, and Dow Jones. BigQuery is used by UPS to predict the exact volume of packages for its various services.

BigQuery is used by Twitter to help with ad updates and the combining of millions of data points per second.

The following are the features offered by BigQuery for data privacy and protection of your data. These include:

• Encryption at rest
• Integration with Cloud Identity
• Network isolation
• Access Management for granular access control

Does PostgreSQL Work As a Data Warehouse?

Yes, you can use PostgreSQL as a data warehouse. But, the main challenges are,

• A data engineer will have to build a data warehouse architecture on top of the existing design of PostgreSQL. To store and build models, you will need to create multiple interlinked databases. But, as PostgreSQL lacks the capability for advanced analytics and reporting, this will further limit the use of it.
• PostgreSQL can’t handle the data processing of huge data volume. Data warehouses have the features such as parallel processing for advanced queries which PostgreSQL lacks. This level of scalability and performance with minimal latency is not possible with the database.

Methods to Set up PostgreSQL to BigQuery Integration

For the scope of this blog, the main focus will be on Method 1 and detail the steps and challenges. Towards the end, you will also get to know about both methods, so that you have the right details to make a choice. Below are the 2 methods:

Method 1: Using Hevo Data to Set Up PostgreSQL to BigQuery Integration

The steps to load data from PostgreSQL to BigQuery using Hevo Data are as follows:

• Step 1: Connect your PostgreSQL account to Hevo’s platform. Hevo has an in-built PostgreSQL Integration that connects to your account within minutes.

The available ingestion modes are Logical Replication, Table, and Custom SQL. Additionally, the XMIN ingestion mode is available for Early Access. Logical Replication is the recommended ingestion mode and is selected by default.

• Step 2: Select Google BigQuery as your destination and start moving your data.

With this, you have successfully set up Postgres to BigQuery replication using Hevo Data.

Here are more reasons to try Hevo:

• Schema Management: Hevo takes away the tedious task of schema management & automatically detects the schema of incoming data and maps it to the destination schema.
• Incremental Data Load: Hevo allows the transfer of data that has been modified in real-time. This ensures efficient utilization of bandwidth on both ends.
• Data Transformation: It provides a simple interface to perfect, modify, and enrich the data you want to transfer.

Method 2: Manual ETL Process to Set Up PostgreSQL to BigQuery Integration

The COPY command is used to migrate data from PostgreSQL tables and standard file-system files. It can be used as a normal SQL statement with SQL functions or PL/pgSQL procedures which gives a lot of flexibility to extract data as a full dump or incrementally.

The picture given above represents the high-level steps to be followed to migrate Postgres to BigQuery:

• Step 1: Extract Data from PostgreSQL
• Step 2: Transform Data
• Step 3: Upload to Google Cloud Storage(GCS)
• Step 4: Upload to the BigQuery Table from GCS
• Step 5: Update Target Table in BigQuery

Let’s take a detailed look at each step.

Step 1: Extract Data From PostgreSQL

COPY TO command is the well-accepted method to extract data from the PostgreSQL table. You can also consider using the pg_dump utility for the first time for full data extraction. This blog post will cover both methods.

a. Data Extraction using the COPY command

Copy Command is the most efficient way to move data between PostgreSQL tables and the standard file system. The COPY TO command copies the results of a SELECT query or contents of a table to that file. The syntax of Commands is:

COPY table_name or query TO file_name WITH options.

Example:

COPY persons TO 'C:tmppersons_db.csv'  WITH DELIMITER ',' CSV HEADER;
COPY (select * from persons where age >25) TO 'C:tmppersons_db.csv'  WITH DELIMITER ',' CSV HEADER;

Some frequently used options:

• FORMAT – Data format to be read or written: text, CSV, or binary. By default, this is set to text.
• DELIMITER- This indicates what character separates columns within each row of the file.
• NULL – This is the string that represents a null value. By default, it is an unquoted empty string in CSV format and N (backslash-N) in text format.
• HEADER – In the output file, the column names/headers are from the table. These are mentioned in the first line.
• QUOTE – When a data value is quoted, this specifies the quoting character to be used. A double-quote is used by default.
• ESCAPE – This represents the character that should appear before the data character that matches the value for QUOTE.
• ENCODING – This specifies the encoding of the output file. The existing client encoding is used, if this option is not specified.

Now, let’s look into how the COPY command can be used to extract data from multiple tables using a procedure. The list_of_tables contains details of tables to be exported.

CREATE OR REPLACE FUNCTION to_csv(path TEXT) RETURNS void AS $
declare
   tables RECORD;
   statement TEXT;
begin
FOR tables IN
   SELECT (table_schema || '.' || table_name) AS schema_table
   FROM list_of_tables
LOOP
   statement := 'COPY ' || tables.schema_table || ' TO ''' || path || '/' || tables.schema_table || '.csv' ||''' DELIMITER '';'' CSV HEADER';
   EXECUTE statement;
END LOOP;
return;
end;
$ LANGUAGE plpgsql;

SELECT db_to_csv('/home/user/dir'); -- This will create one csv file per table, in /home/user/dir/

If you want to extract data incrementally, add more metadata like the timestamp of the last data extraction to table list_of_tables and use that information while creating a copy command to extract data changed after that timestamp.

For example, say you are using a column name last_success_pull_time corresponding to each table in the table list_of_tables which stores the last successful data pull time.

Each time data in the table which are modified after that timestamp has to be pulled. The body of the loop in the procedure will change like this:

Here, a dynamic SQL is created with a predicate comparing last_modified_time_stamp  from the table to be extracted and last_success_pull_time from table list_of_tables.

begin
FOR tables IN
   SELECT (table_schema || '.' || table_name) AS schema_table, last_success_pull_time AS lt
   FROM list_of_tables
LOOP
   statement := 'COPY (SELECT * FROM ' || tables.schema_table ||   ' WHERE last_modified_time_stamp > ' || last_success_pull_time ')  TO ' '' || path || '/' || tables.schema_table || '.csv' ||''' DELIMITER '';'' CSV HEADER';
   EXECUTE statement;
END LOOP;
return;
End;

b. Extract data using the pg_dump

pg_dump is a utility for backing up a PostgreSQL database. It can be used to extract data from the table also.

pg_dump --column-inserts --data-only --table=<table> <database> > my_dump.sql

Here, the output file table_name.sql will be in the form of insert statements like

INSERT INTO table_name (column1, column2, column3, ...)
VALUES (value1, value2, value3, ...);

This output has to be converted into a CSV file. You have to write a small script to perform this.

Step 2: Transform Data

Apart from transformations to accommodate business logic, there are some basic things to keep in mind while preparing data for BigQuery.

• BigQuery expects CSV data to be UTF-8 encoded. If data is encoded in ISO-8859-1(Latin-1), explicitly specify it while loading to BigQuery.
• BigQuery doesn’t enforce Primary Key and unique key constraints. Your ETL process has to take care of that.
• Column types are slightly different between Postgres and BigQuery. Most of the types have either equivalent or convertible types. The following table contains a list of common data types.

PostgreSQL Data Type	BigQuery Data Type
TINYINT	INT64
SMALLINT	INT64
MEDIUMINT	INT64
INT, INTEGER	INT64
BIGINT	INT64
DECIMAL	NUMERIC
NUMERIC(p,s)	NUMERIC
REAL	FLOAT64
DOUBLE PRECISION	FLOAT64
BOOLEAN	BOOL
CHAR(n), CHARACTER(n)	STRING
VARCHAR(n)	STRING
BYTEA	BYTES
TINYTEXT	STRING
TEXT	STRING
MEDIUMTEXT	STRING
LONGTEXT	STRING
ENUM	No type for ENUM.Must use any type which can represent values in ENUM
DATE	DATE
TIME [WITHOUT TIME ZONE]	TIME
TIMESTAMP [WITHOUT TIME ZONE]	TIMESTAMP

You can visit their official page to know more about BigQuery data types.

• DATE value must be a dash(-) separated and in the form YYYY-MM-DD (year-month-day).

Fortunately, the default date format in Postgres is the same, YYYY-MM-DD.So if you are simply selecting date columns it should be the incorrect format.

If the data is stored as a string in the table for any reason, it can be converted while selecting data.

The TO_DATE function in PostgreSQL helps in converting string values into dates.

Syntax : TO_DATE(str,format)
Example : SELECT  TO_DATE('31,12,1999','%d,%m,%Y');
Result : 1999-12-31

• In TIMESTAMP type, the hh:mm:ss (hour-minute-second) portion must use a colon (:) separator.

Similar to the Date type, The TO_TIMESTAMP function in PostgreSQL is used to convert strings into timestamps.

Syntax : TO_TIMESTAMP(str,format)
Example : SELECT TO_TIMESTAMP('2017-03-31 9:30:20','YYYY-MM-DD HH:MI:SS');
Result: 2017-03-31 09:30:20-07

• Make sure text columns are quoted if they can potentially have delimiter characters.

Step 3: Upload to Google Cloud Storage(GCS)

There are multiple ways in which you can achieve this:

Using Gsutil:

Gsutil is the standard tool from GCP to handle objects and buckets in GCS. It has options to upload a file from your local machine to GCS.

To copy a file to GCS :

gsutil cp table_data.csv  gs://my-bucket/path/to/folder/

To copy an entire folder :

gsutil cp -r dir gs://my-bucket/path/to/parent/

If the files to be copied are already in S3, the same command can be used to transfer them to GCS. Note that AWS credentials should be present in the default path to work this.

gsutil cp -R s3://bucketname/source/path gs://bucketname/destination/path

Storage Transfer Service:

Storage Transfer Service from Google Cloud Platform is another alternative to upload files to GCS from S3 or other online data sources like HTTP/HTTPS location given destination or sink is Cloud Storage bucket. A GCS bucket can also be the source.

When it comes to moving data to GCS, this service is extremely useful. Here are the top reasons to use Storage Transfer Service:

• Using the Storage Transfer service, you can schedule both repeating and one-time transfers.
• If no corresponding source object is present, the service supports the deletion of existing objects in the destination. This is very helpful in syncing source and destination.
• After transferring data, you can delete the source object.
• The service supports source and sink synchronization with advanced filters like file creation dates, file names, etc.

Upload Data from Web Console:

In case you are uploading data from the local machine, you can use web console UI to upload files to GCS. The steps along with relevant screenshots are mentioned below:

1. First thing, you will have to log in to your GCP account. On the left sidebar, click on Storage and go to the Browser.

2. Select the GCS bucket that you want to upload the file. Here the bucket is named test-data-hevo. Click on the bucket.

3. In the bucket details page, you have to click on the Upload files button and select relevant files from your system.
4. Once the upload is completed, the file will be listed in the bucket as follows :

Step 4: Upload to the BigQuery Table from GCS

You can use web console UI or a command-line tool called bq to load data to the BigQuery table. First, let’s look into how to achieve this using the web console:

• Go to the BigQuery console from the left side panel.

• Create a Dataset if not present already.

• Now click on the created datasets on the left side. Then create table option will appear below the Query editor.

• Create Table button will open a wizard with options to specify input source and other specifications for the table.

As shown in the screenshot, there are options to specify schema or auto-detect. There are many more options available. Feel free to choose them as per your need.

To interact with BigQuery, you can use bq, the command-line tool. Using this tool, uploading data to GCS is a cakewalk. All you need to do is use the bq load command and specify CSV as the source_format.

The syntax of bq load:

bq --location=[LOCATION] load --source_format=[FORMAT] [DATASET].[TABLE] [PATH_TO_SOURCE] [SCHEMA]

• [LOCATION] is an optional parameter and represents your Location.
• [FORMAT] is to be set to CSV.
• [DATASET] represents an existing dataset.
• [TABLE] is the table name into which you’re loading data.
• [PATH_TO_SOURCE] is a fully-qualified Cloud Storage URI.
• [SCHEMA] is a valid schema. The schema must be a local JSON file or inline.
• Note that here an autodetect flag can also be used instead of supplying a schema definition.

There are a bunch of options specific to CSV data load:

CSV option	bq command flag	Description
Field Delimiter	-F or –field_delimiter	Field delimiter: Comma, Tab, Pipe, Other
Header rows	–skip_leading_rows	Header rows to skip
Number of bad records allowed	–max_bad_records	Number of errors allowed
Newline characters	–allow_quoted_newlines	Allow quoted newlines
Custom null values	–null_marker	Specifies a string that represents a null value in a CSV file
Trailing optional columns	–allow_jagged_rows	Allow jagged rows
Unknown values	–ignore_unknown_values	Ignore unknown values
Quote	–quote	The value that is used to quote data sections in a CSV file
Encoding	-E or –encoding	The character encoding of the data

Refer to BigQuery documentation to explore more about data cloud storage CSV.

For Schema Specification using a JSON file:

bq --location=US load --source_format=CSV your_dataset.your_table gs://your_bucket/your_data.csv ./your_schema.json

For schema auto-detection using file:

bq --location=US load --autodetect --source_format=CSV your_dataset.your_table  gs://mybucket/data.csv

BigQuery offers 3 options to write to an existing table:

1. Write if empty.
2. Append to the table.
3. Overwrite table.

Additionally, while uploading data it is possible to add new fields to the table. Here is an example.

Overwriting existing table:

bq --location=US load --autodetect --replace --source_format=CSV your_dataset.your_table gs://mybucket/your_data.csv

Appending data to the existing table:

bq --location=US load --autodetect --noreplace --source_format=CSV your_dataset.your_table gs://mybucket/your_data.csv ./your_schema.json

Adding a new field to the table. Here, the new schema file with an extra field is given :

bq --location=asia-northeast1 load --noreplace --schema_update_option=ALLOW_FIELD_ADDITION --source_format=CSV your_dataset.your_table gs://mybucket/your_data.csv ./your_schema.json

Step 5: Update Target Table in BigQuery

Upload the data into a staging table before upserting newly extracted data to the BigQuery table. It needs to be a full load. Refer to the full data load section above for more details.

Let’s call it intermediate_delta_table. You can refer to any of the following two steps to load data to the target table :

a. Update the values of existing records in the final table and insert new rows from the delta table which are not in the final table.

UPDATE data_set.final_target_table t
SET t.value = s.value
FROM  data_set.intermediate_delta_table s
WHERE t.id = s.id;

INSERT data_set.final_target_table (id, value)
SELECT id, value
FROM  data_set.intermediate_delta_table
WHERE NOT id IN (SELECT id FROM data_set.final_target_table);

b. Delete rows from the final table which are present in the delta table. Then insert all rows from the delta table to the final table.

DELETE data_set.final_target_table f
WHERE f.id IN (SELECT id from data_set.intermediate_delta_table);

INSERT data_set.final_target_table (id, value)
SELECT id, value
FROM  data_set.intermediate_delta_table;

Limitations of Manual ETL Process to Set Up PostgreSQL to BigQuery Integration

In the modern era of data-driven business, getting value from data should be quick with minimum friction. Data Warehouses like BigQuery play an extremely important role in this. Below are the limitations associated with replicating data from PostgreSQL to BigQuery:

1. Moving data to these cloud-based solutions takes multiple steps like extract data, clean/transform it and upload.
2. It requires huge engineering resources and time to ensure data correctness and consistency across the process.

Benefits of Replicating Data to Google BigQuery

Here are some points to be considered in PostgreSQL to BigQuery replication.

• BigQuery automatically scales both up and down based on data volume and the complexities of queries. Cluster sizing or scaling is easily handled by BigQuery which means it is truly serverless.
• There is no cost for infrastructure. We have to pay for storing data ($0.020 per GB per month) and for querying data ($5 per 1 TB of data analyzed). BigQuery is storing data in columnar format. So most of the time volume of data analyzed for the query is much lesser than the total table size. Please refer to their website to know the recent pricing details.
• Google BigQuery supports streaming data into the destination table without impacting query performance.
• All the data in BigQuery is encrypted by default. Security is guaranteed and no user configuration is required.
• BigQuery supports semi-structured data like JSON format. One does not have to convert it to relational data.
• The Google Cloud team has added ML modules on top of BigQuery. These ML models can be created and trained using basic SQL.

Additional Resources for PostgreSQL Integrations and Migrations

• Postgresql on Google Cloud Sql to Bigquery
• Heroku for Postgresql to Bigquery
• Migrate Data from Postgres to MySQL
• How to migrate Data from PostgreSQL to SQL Server
• Connecting PostgreSQL to Power BI
• PostgreSQL to Oracle Migration
• Connect PostgreSQL to MongoDB
• Connect PostgreSQL to Redshift
• Integrate Postgresql to Databricks
• Replicate Postgres to Snowflake
• Export a PostgreSQL Table to a CSV File

Conclusion

This article provided an introduction to PostgreSQL and BigQuery and explained their features. Moreover, it elaborated on the 2 methods which you can use to sync PostgreSQL to BigQuery.

The manual method, although effective, will require a lot of time and resources. Data Migration from PostgreSQL to BigQuery is a painful and time taking process but using a data integration tool like Hevo can perform this process with no effort and no time.

Want to try Hevo? Sign Up for a 14-day free trial and experience the feature-rich Hevo suite firsthand. Have a look at
