Using Pandas Redshift: Analyzing and Visualizing Data Simplified 101

Redshift is Amazon Web Services (AWS) Cloud Data Warehouse. AWS provides an efficient way for organizations to collect, store, and analyze their data using various Business Intelligence tools. Python modules offer a rich ecosystem for getting started quickly and effectively integrating your systems.

This article will demonstrate the easiest way to analyze and visualize using Pandas Redshift for analysis and Plotly’s public platform for displaying beautiful, interactive visuals and graphs in Python.

Table of Contents

• What is Pandas?
• What is Amazon Redshift?
• Importing Libraries
• Connecting Pandas Redshift
  • Loading the Data
  • Analysis and Visualization
    • Plotting Heatmap Graphs
    • Plotting Box Plots
    • Plotting Simple Bar Chart
• Conclusion

What is Pandas?

Pandas is a Python Data Analysis and Manipulation Library that is open-source. It uses a data structure known as a DataFrame to analyze and alter two-dimensional data. Pandas also include Data Cleansing, Data Exploration, and Visualization tools in addition to Data Analysis and Manipulation.

What is Amazon Redshift?

Amazon Redshift, also known as Amazon Web Services Redshift, is a Cloud-based serverless data warehouse offered by Amazon as part of Amazon Web Services (AWS). Many firms prefer it since it is a fully managed and cost-effective Data Warehousing Solution. AWS Redshift is meant to store petabytes of data and perform Real-time Redshift Analytics to provide actionable insights and assist businesses in growing.

In contrast to typical databases, which store data in rows, AWS Redshift is a column-oriented database that saves user data in a columnar format. To perform computation and generate vital insights, Amazon Redshift uses its own compute engine.

Check out our entire guide, AWS Redshift Database in 2021: A Comprehensive Guide, for more information on AWS Redshift. AWS Redshift Best Practices for 2022 is another useful blog that highlights best practices for utilizing Amazon Redshift.

Importing Libraries

In this tutorial, the data you will use is Amazon’s Sample Redshift Data. Although you will not be using JDBC/ODBC, you will be using the psycopg2 package with SQLAlchemy and Pandas Redshift to simplify analyzing and querying data.

from __future__ import print_function

import plotly.plotly as py
import plotly.graph_objs as go
import plotly.tools as tls
import pandas as pd
import os
import requests

Connecting Pandas Redshift

To access your Redshift instance, you need the Redshift Endpoint URL. For example, instances will look something like this:

datawarehouse.some_chars_here.region_name.redshift.amazonaws.com.

Once you’ve configured your cluster, Redshift is extremely easy to connect. Include Username, Password, Port, Host, and Database name in this configuration.

redshift_endpoint = os.getenv("REDSHIFT_ENDPOINT")
redshift_user = os.getenv("REDSHIFT_USER")
redshift_pass = os.getenv("REDSHIFT_PASS")
port = 5439
dbname = 'dev'

Redshift Databases can be accessed in several ways, and there are listed two below. In addition, the SQLAlchemy package can be used for more direct access, and the psycopg2 package.

You can execute SQL queries and get results, but SQLAlchemy is a bit more convenient for returning data directly as a dataframe with Pandas Redshift. Additionally, Plotly integrates tightly with Pandas Redshift, making creating interactive graphs with your team easy.

SQLAlchemy

from sqlalchemy import create_engine
engine_string = "postgresql+psycopg2://%s:%s@%s:%d/%s"
% (redshift_user, redshift_pass, redshift_endpoint, port, dbname)
engine = create_engine(engine_string)

Psycopg2

import psycopg2
conn = psycopg2.connect(
   host="datawarehouse.cm4z2iunjfsc.us-west-2.redshift.amazonaws.com",
    user=redshift_user,
    port=port,
    password=redshift_pass,
    dbname=dbname)
cur = conn.cursor() # create a cursor for executing queries

1) Loading the Data

Here is the explanation of how to load data from Amazon’s sample database for the Pandas Redshift connection. You can skip this section if you will be working with your own data.

Start loading the data

cur.execute("""drop table users;
drop table venue;
drop table category;
drop table date;
drop table event;
drop table listing;
drop table sales;""")
conn.commit()

aws_key = os.getenv("AWS_ACCESS_KEY_ID") # Required for accessing S3 samples
aws_secret = os.getenv("AWS_SECRET_ACCESS_KEY")

base_copy_string = """copy %s from 's3://awssampledbuswest2/tickit/%s.txt'
credentials 'aws_access_key_id=%s;aws_secret_access_key=%s'
delimiter '%s';""" # This will be our base COPY string

#Easy step by step instructions to generate each table where we will need COPY data
tables = ["users", "venue", "category", "date", "event", "listing"]
data_files = ["allusers_pipe", "venue_pipe", "category_pipe", "date2008_pipe", "allevents_pipe", "listings_pipe"]
delimiters = ["|", "|", "|", "|", "|", "|", "|"]

#these are COPY statements we'll be using for loading the data;
copy_statements = []
for tab, f, delim in zip(tables, data_files, delimiters):
    copy_statements.append(base_copy_string % (tab, f, aws_key, aws_secret, delim))

# add in Sales data, delimited by 't'
copy_statements.append("""copy sales from 's3://awssampledbuswest2/tickit/sales_tab.txt'
credentials 'aws_access_key_id=%s;aws_secret_access_key=%s'
delimiter 't' timeformat 'MM/DD/YYYY HH:MI:SS';""" % (aws_key, aws_secret))

# Creating Table Statements
cur.execute("""
create table users(
	userid integer not null distkey sortkey,
	username char(8),
	firstname varchar(30),
	lastname varchar(30),
	city varchar(30),
	state char(2),
	email varchar(100),
	phone char(14),
	likesports boolean,
	liketheatre boolean,
	likeconcerts boolean,
	likejazz boolean,
	likeclassical boolean,
	likeopera boolean,
	likerock boolean,
	likevegas boolean,
	likebroadway boolean,
	likemusicals boolean);

create table venue(
	venueid smallint not null distkey sortkey,
	venuename varchar(100),
	venuecity varchar(30),
	venuestate char(2),
	venueseats integer);

create table category(
	catid smallint not null distkey sortkey,
	catgroup varchar(10),
	catname varchar(10),
	catdesc varchar(50));

create table date(
	dateid smallint not null distkey sortkey,
	caldate date not null,
	day character(3) not null,
	week smallint not null,
	month character(5) not null,
	qtr character(5) not null,
	year smallint not null,
	holiday boolean default('N'));

create table event(
	eventid integer not null distkey,
	venueid smallint not null,
	catid smallint not null,
	dateid smallint not null sortkey,
	eventname varchar(200),
	starttime timestamp);

create table listing(
	listid integer not null distkey,
	sellerid integer not null,
	eventid integer not null,
	dateid smallint not null sortkey,
	numtickets smallint not null,
	priceperticket decimal(8,2),
	totalprice decimal(8,2),
	listtime timestamp);

create table sales(
	salesid integer not null,
	listid integer not null distkey,
	sellerid integer not null,
	buyerid integer not null,
	eventid integer not null,
	dateid smallint not null sortkey,
	qtysold smallint not null,
	pricepaid decimal(8,2),
	commission decimal(8,2),
	saletime timestamp);""")

for copy_statement in copy_statements: # execute each COPY statement
    cur.execute(copy_statement)
conn.commit()

for table in tables + ["sales"]:
    cur.execute("select count(*) from %s;" % (table,))
    print(cur.fetchone())
conn.commit() # Ensure that the data has been processed and commit our statements.

Pandas Redshift connection is complete. You can now start running queries on the data you loaded into Redshift.

2) Analysis and Visualization

Now next step of Pandas Redshift process is to look for insights. You’ll look at some of the user’s preferences and habits as a first step. It is easy to query the database with Pandas and return a dataframe. In this case, retrieving user preferences. What kind of events are they interested in?

df = pd.read_sql_query("""
SELECT sum(likesports::int) as sports, sum(liketheatre::int) as theatre,
sum(likeconcerts::int) as concerts, sum(likejazz::int) as jazz,
sum(likeclassical::int) as classical, sum(likeopera::int) as opera,
sum(likerock::int) as rock, sum(likevegas::int) as vegas,
sum(likebroadway::int) as broadway, sum(likemusicals::int) as musical,
state
FROM users
GROUP BY state
ORDER BY state asc;
""", engine)

A) Plotting Heatmap Graph

Now that DataFrame has been returned, let’s make a quick heatmap using plotly.

data = [
        go.Heatmap(
            z = df.drop('state', axis=1).values,
            x = df.drop('state', axis=1).columns,
            y = df.state,
            colorscale = 'Hot'
        )
    ]
layout = go.Layout(title="State and Music Tastes", yaxis=dict(autotick=False, dtick=1))
py.iplot(Figure(data=data, layout=layout), filename='redshift/state and music taste heatmap', height=1000)

Producing this graph is straightforward, and exploring it is even simpler. By examining this particular graph, you can easily see that it is quite popular. Clearly, sports events don’t seem very popular with the users, and certain states have higher preferences (and possibly a more significant number of users) than others.

B) Plotting Box Plots

Making some box plots based on these user preferences is what you are going to do now.

layout = go.Layout(title="Declared User Preference Box Plots",
                yaxis=dict())

data = []
for pref in df.drop('state', axis=1).columns:
    # for every preference type, make a box plot
    data.append(go.Box(y=df[pref], name=pref))

py.iplot(go.Figure(data=data, layout=layout), filename='redshift/user preference box plots')

Sports seem to be a little bit compressed compared to other activities. Maybe there are fewer sports enthusiasts, or our company doesn’t host many sporting events.

Following a quick exploration of a few of the customers, you have found this sports anomaly. Should there be fewer sports events listed? Do users just don’t like sports events? Is there a difference in the number of sales between event types?

C) Plotting Simple Bar Chart

The information needs to be visualized in a simple bar graph to understand it a bit better.

df = pd.read_sql_query("""
SELECT sum(event.catid) as category_sum, catname as category_name
FROM event, category
where event.catid = category.catid
GROUP BY category.catname
""", engine)

layout = go.Layout(title="Event Categories Sum", yaxis=dict(title="Sum"))
data = [go.Bar(x=df.category_name, y=df.category_sum)]
py.iplot(go.Figure(data=data, layout=layout))

As soon as you started researching this data, you found a discrepancy between the users’ preferences and the types of events you’re hosting! You need to report this to management! Let’s take a closer look at the events you are listing. Are there any event types trending upward?

df = pd.read_sql_query("""
SELECT sum(sales.qtysold) as quantity_sold, date.caldate
FROM sales, date
WHERE sales.dateid = date.dateid
GROUP BY date.caldate
ORDER BY date.caldate asc;
""", engine)

layout = go.Layout(title="Event Sales Per Day", yaxis=dict(title="Sales Quantity"))
data = [go.Scatter(x=df.caldate, y=df.quantity_sold)]
py.iplot(go.Figure(data=data, layout=layout))

The results seem to be inconclusive, except for the seasonality of our events. Unfortunately, the aggregate graph does not show much here, so it would probably be worthwhile to explore each category a bit more.

df = pd.read_sql_query("""
SELECT sum(sales.qtysold) as quantity_sold, date.caldate, category.catname as category_name
FROM sales, date, event, category
WHERE sales.dateid = date.dateid
AND sales.eventid = event.eventid
AND event.catid = category.catid
GROUP BY date.caldate, category_name
ORDER BY date.caldate asc;
""", engine)

You always need to figure out what kind of graph will communicate your message most effectively. Subplots sometimes work well, but sometimes it’s best to plot them all together. Both are easy with Plotly!

data = []
for count, (name, g) in enumerate(df.groupby("category_name")):
    data.append(go.Scatter(
            name=name,
            x=g.caldate,
            y=g.quantity_sold,
            xaxis='x' + str(count + 1),
            yaxis='y' + str(count + 1)
        ))

fig = tls.make_subplots(rows=2,cols=2)
fig['layout'].update(title="Event Sales Per Day By Category")
fig['data'] += data
py.iplot(fig)

Your plot grid is formatted as follows:

[ (1,1) x1,y1 ] [ (1,2) x2,y2 ]
[ (2,1) x3,y3 ] [ (2,2) x4,y4 ]

While the above subplots seem to tell a compelling story, it should be noted that axes aren’t always aligned with subplots. It would be useful to plot them all together, with lines indicating the categories.

data = []
for name, g in df.groupby("category_name"):
    data.append(go.Scatter(
            name=name,
            x=g.caldate,
            y=g.quantity_sold
        ))

fig = go.Figure()
fig['layout'].update(title="Event Sales Per Day By Category")
fig['data'] += data
py.iplot(fig, filename='redshift/Event Sales Per Day by Category')

This explains the scenario much better and looks much better. You seem to have quite a few events throughout the year, with the exception of a flurry of musicals around March.

Conclusion

Python’s rich ecosystem of modules allows you to integrate your systems more efficiently and get up to speed quickly. For example, you can easily create beautiful visualizations and analyze data using Pandas Redshift, plotly, and the SQLAlchemy toolkit. In case you want to export data from various sources into your desired Database/destination like Redshift, then Hevo Data is the right choice for you!
